Sorry, this product is no longer available, replaced by the EX2300-24P.

Download the software package (s) you need from the Juniper Networks Web site. Perform a system backup on the router you wish to upgrade. Copy the software package (s) to the router you wish to upgrade. Add the new software package (s) to the router you wish to upgrade (this will effectively delete the old packages). Reboot the router. This article provides step-by-step instructions for installing Junos on an EX Switch using the method where the Junos software package exists on an external server or remote location. Solution: The instructions for the Junos installation on an EX switch are covered in the Technical Documentation: Install Junos on EX Switch using CLI (steps 4-6). (CVSS:4.4) (Last Update:2016-12-03) CVE-2015-2790 Foxit Reader, Enterprise Reader, and PhantomPDF before 7.1 allow remote attackers to cause a denial of service (memory corruption and crash) via a crafted (1) Ubyte Size in a DataSubBlock structure or (2) LZWMinimumCodeSize in a GIF image. Juniper Ex2200 Firmware Update How To Install Firmware Update On Lg Phone The 802.1X daemon (dot1xd) receives a delete message for the physical interface (ifd) from the kernel, but does not clear the sessions associated with the interface.


Overview:

High-performance businesses demand high-performance networking solutions. The Juniper Networks EX2200 Ethernet Switch offers an economical, entry-level, stand-alone solution for access-layer deployments in branch and remote offices, as well as campus networks.

The EX2200 also supports Juniper Networks Virtual Chassis technology, allowing up to four interconnected switches to be managed as a single logical device, delivering a scalable, pay-as-you-grow solution for expanding networks.

Featuring complete Layer 2 and basic Layer 3 switching capabilities, the Juniper Networks® EX2200 line of fixed configuration Ethernet switches with Virtual Chassis technology satisfies the branch and low-density wiring closet connectivity requirements of today’s high-performance businesses. Four platform configurations are available offering 24 and 48 10/100/1000BASE-T ports with or without Power over Ethernet (PoE). The PoE- enabled EX2200 models include a maximum system budget of 405 W to deliver up to 15.4 watts of standards-based 802.3af Class 3 PoE or 30 watts of standards-based 802.3at PoE+ for supporting networked devices such as telephones, video cameras, multiple radio IEEE 802.11n wireless LAN (WLAN) access points and video phones in converged networks.

Juniper

Additional features include:

  • Four front panel small form-factor pluggable transceiver (SFP) GbE uplink ports provide high-speed connectivity to aggregation layer switches or other upstream devices.
  • Uplink ports can be configured as Virtual Chassis interfaces and connected via standard GbE optics interfaces. The last two uplinks are preconfigured by default as Virtual Chassis ports.
  • Fixed power supply and uplink ports ensure operational simplicity.
  • Low power consumption, low acoustic fans, and small 10-inch wide footprint enable flexible, environmentally friendly deployment.
  • Support for L2 protocols as well as L3 protocols like RIP and static routing in base license.
  • Optional enhanced license for supporting additional L3 protocols such as OSPF, Internet Group Management Protocol (IGMP v1/v2/v3), Protocol Independent Multicast (PIM), IEEE 802.1 Q-in-Q, Bidirectional Forwarding Detection (BFD), Virtual Router Redundancy Protocol (VRRP) and Virtual Router / VRF-Lite.
  • IPv6 management support including neighbor discovery, telnet, SSH, DNS, syslog and NTP.
  • Single release train for Juniper Networks Junos® operating system ensures consistent control plane feature implementation.
  • Modular Junos OS prevents a switch reboot if a single protocol feature fails.
  • Managed through a single application, Juniper Networks Network and Security Manager.
  • Integrates with Juniper Networks Unified Access Control to provide per-user access control and policing.
  • Enhanced limited lifetime switch hardware warranty.
  • Built-in Web interface (Juniper Networks J-Web Software).

Product Overview

The Juniper Networks EX2200 line of Ethernet switches offers a compact, high-performance solution for supporting today’s converged network access deployments.

Each EX2200 switch includes an application-specific integrated circuit (ASIC)-based Packet Forwarding Engine (PFE) with an integrated CPU to consistently deliver wire-rate forwarding, even with all control plane features enabled. Based on existing, field proven Juniper Networks technology, the PFE brings the same level of carrier-class performance and reliability to the EX2200 switches that Juniper Networks routers bring to the world’s largest service provider networks.

Architecture and Key Components:

The EX2200 occupies a single rack unit, delivering a compact solution for crowded wiring closets and access locations where space and power are at a premium. The EX2200 switch’s 10-inch depth and low acoustics also make it ideal for open office deployments.

Each EX2200 switch supports four fixed front panel GbE uplink ports with pluggable optics (purchased separately) for high-speed backbone or link aggregation connections between wiring closets and upstream aggregation switches. The EX2200 also features a front panel mode button that offers a simple interface for bringing devices up and selecting LED modes.

A dedicated rear panel RJ-45 Ethernet port is available for out-of- band management, while a rear panel USB port can be used to easily upload the Junos operating system and configuration files.


The EX2200 line provides a high-performance solution for converged networks in branch offices as well as campus wiring closets.

Juniper Ex2200 Firmware Update

Virtual Chassis Technology:

The EX2200 supports Juniper’s unique Virtual Chassis technology, enabling up to four interconnected EX2200 switches to be managed as a single logical device, delivering a scalable, pay-as- you-grow solution for expanding network environments.

While EX2200 switches can be interconnected over any of the front-panel uplink ports, the last two ports are configured by default as Virtual Chassis ports, automating deployments when using standard GbE SFP transceivers (sold separately). These two ports can also be configured as GbE uplinks to aggregation devices by disabling the Virtual Chassis technology.

When deployed in a Virtual Chassis configuration, the EX2200 switches elect a master and a backup switch based on a set of preconfigured policies or criteria. The master switch automatically creates and updates the switching and optional routing tables on all other Virtual Chassis switch members. Switches can be added to or removed from the Virtual Chassis configuration without service disruption.

EX2200 Virtual Chassis configurations operate as highly resilient unified systems, providing simplified management using a single IP address, single telnet session, single command-line interface (CLI), automatic version checking, and automatic configuration. The EX2200 switches are also capable of local switching, so packets coming into a port destined for another port on the same switch do not have to traverse the Virtual Chassis, increasing forwarding capacities.

EX2200 Virtual Chassis configurations implement the same slot/ module/port numbering schema as other Juniper Networks chassis- based products, providing true chassis-like operations. By using

a consistent operating system and a single configuration file, all switches in a Virtual Chassis configuration are treated as a single device, simplifying overall system maintenance and management.

Features and Benefits:

High Availability Features

  • Redundant Trunk Group (RTG): To avoid the complexities of the Spanning Tree Protocol (STP) without sacrificing network resiliency, the EX2200 employs a redundant trunk group to provide the necessary port redundancy and simplify switch configuration.
  • Power resiliency through external redundant power supply: The EX2200 supports an optional redundant power supply (RPS) unit which provides power resiliency.

Junos Operating System

The EX2200 runs the same Junos OS used by other Juniper Networks EX Series Ethernet Switches, as well as all of Juniper’s routers and Juniper Networks SRX Series Services Gateways. By utilizing a common operating system, Juniper delivers a consistent implementation and operation of control plane features across all products. To maintain that consistency, Junos OS adheres to a highly disciplined development process that uses a single source code, follows a single quarterly release train, and employs a highly available modular architecture that prevents isolated failures from bringing down an entire system.

These attributes are fundamental to the core value of the software, enabling all Junos OS-powered products to be updated simultaneously with the same software release. All features are fully regression-tested, making each new release a true superset of the previous version; customers can deploy the software with complete confidence that all existing capabilities will be maintained and operate in the same way.

Converged Environments

The EX2200 provides the highest levels of flexibility and features in its class for the most demanding converged data, voice, and video environments, delivering a reliable platform for unifying enterprise communications.

By providing a full 15.4 watts of Class 3 PoE to VoIP telephones, closed-circuit security cameras, wireless access points, and other IP-enabled devices, the EX2200 delivers a future proofed solution for converging disparate networks onto a single IP infrastructure. The EX2200 PoE switches also support 802.3at standards-based PoE+ for powering networked devices like multiple radio IEEE 802.11n wireless access points, and video phones that may require more power than available with IEEE 802.3af.

To ease deployment, the EX2200 supports the industry-standard Link Layer Discovery Protocol (LLDP) and LLDP-Media Endpoint Discovery (LLDP-MED) protocol, enabling the switches to automatically discover Ethernet-enabled devices, determine their power requirements, and assign virtual LAN (VLAN) membership. LLDP-MED-based granular PoE management allows the EX2200 to negotiate PoE usage down to a fraction of a watt on powered devices, enabling more efficient PoE utilization across the switch.

In addition, the EX2200 supports rich quality-of-service (QoS) functionality for prioritizing data, voice, and video traffic. The switches support eight class-of-service (CoS) queues on every port, enabling them to maintain multilevel, end-to-end traffic prioritizations. The EX2200 also support a wide range of policy options, including strict priority, low-latency, weighted random early detection (WRED), and shaped deficit weighted round-robin (SDWRR) queuing.

Security

The EX2200 fully integrates with Juniper Networks Unified Access Control, which consolidates all aspects of a user’s identity, device, and location. This enables administrators to enforce access control and security down to the individual port or user levels.

Working as an enforcement point within UAC, the EX2200 provides both standards-based 802.1X port-level access control for multiple devices per port, as well as Layer 2-4 policy enforcement based on user identity, location, and/or device. A user’s identity, device type, machine posture check, and location can be used to determine whether access should be granted and for how long. If access is granted, the switch assigns the user’s device to a specific VLAN based on authorization policy. The switch can also apply security policies, QoS policies, or both, or it can mirror user traffic to a central location for logging, monitoring, or threat detection by intrusion prevention systems.

The EX2200 also provides a full complement of integrated port security and threat detection features, including Dynamic Host Configuration Protocol (DHCP) snooping, Dynamic ARP Inspection (DAI), and media access control (MAC) limiting to defend against internal and external spoofing, man-in-the-middle and denial of service (DoS) attacks.

Simplified Management and Operations

When deployed in a Virtual Chassis configuration, the EX2200 dramatically simplifies network management. Up to four interconnected EX2200 switches can be managed as a single device utilizing a single Junos OS image file and a single configuration file, reducing the overall number of units to monitor and manage. When the Junos OS is upgraded on the master switch in an EX2200 Virtual Chassis configuration, the software is automatically upgraded on all other member switches at the same time.

The EX2200 includes port profiles that allow network administrators to automatically configure ports with security, QoS, and other parameters based on the type of device connected to the port. Six preconfigured profiles are available, including default, desktop, desktop plus IP phone, WLAN access point, routed uplink, and Layer 2 uplink. Users can select from the existing profiles or create their own and apply them through the command-line interface (CLI), J-Web Software interface, or management system.

In addition, a feature called system snapshot makes a copy of all software files used to run the switch—including the Junos operating system, the active configuration and the rescue configuration—that can be used to reboot the switch at the next power-up or as a backup boot option. The Junos OS software can also be pre-installed on a flash drive and used to boot the EX2200 at any time.

Another feature, called automatic software download, enables network administrators to easily upgrade the EX2200 using the DHCP message exchange process to download and install software packages. Users simply configure the automatic software download feature on EX2200 switches acting as DHCP clients and establish a path to the server where the software package file is installed. The server then communicates the path to the software package file through DHCP server messages.

An EZ touchless provisioning feature allows a DHCP server to push configuration details and software images to multiple switches at bootup.

Three system management options are available for the EX2200 line. The standard Junos OS CLI management interface offers the same granular capabilities and scripting parameters found in any router powered by the Junos operating system. The EX2200 also includes the integrated J-Web interface, an embedded web- based device manager that allows users to configure, monitor, troubleshoot, and perform system maintenance on individual switches via a browser-based graphical interface.

Finally, EX2200 fault, configuration, and performance data can be exported to leading third-party management systems such as HP OpenView, IBM Tivoli, and Computer Associates Unicenter software, providing a complete, consolidated view of network operations.

Junos Space:

Juniper also offers a comprehensive suite of network management tools that provide a smart, simple, and open approach for automating the deployment and operation of a Juniper infrastructure.

These tools are based on a single network application platform called Juniper Networks Junos® Space, an open, programmable application platform for hosting network infrastructure and operational applications across the entire management life cycle of the network. Explicitly designed to allow partners and customers to build and deploy smart, simple, and easy-to-use applications, Junos Space provides multiple management and infrastructure applications for managing Juniper resources and assets, including inventory management, device and interface configuration, automated software management and deployment, and event- driven fault management. These platform applications are embedded within the core product, allowing users to control any part of their environment when used in conjunction with multiple add-on applications. Junos Space will support a full portfolio of applications for automating network infrastructure and operations covering the campus LAN and data center network environments.

Designed to automate the configuration, visualization, monitoring, and administration of large switch and router networks, these Junos Space applications offer predefined automation schemes and best practice templates to enable rapid and accurate deployments. When managing a group of EX2200 switches,

the Junos Space platform and associated applications provide network-level management across all Juniper Networks switches from a single console.

Enhanced limited Lifetime Warranty

The EX2200 includes an enhanced limited lifetime hardware warranty that provides next business day advance hardware switch replacement for as long as the original purchaser owns the product. The warranty includes lifetime software updates, advanced shipping of spares within one business day, and 24x7 JTAC support for 90 days after the purchase date. Power supplies and fan trays are covered for a period of five years.

Specifications:

Model:EX2200-24P-4G
Physical Specifications
Dimensions (W x H x D)Width: 17.4 in (44.1 cm) for desktop installations
17.5 in (44.6 cm) with rack-mount brackets
Height: 1.75 in (4.45 cm) for 1U installations
Depth: 10 in (25.43 cm)
Weight8 lb (3.6 kg)
Rack mountable1 Rack Unit
Hardware Specifications
Switching Engine ModelStore and forward
DRAM512 MB
Flash1 GB
CPU800 MHz ARM CPU
GbE port density per system28 (24 host ports + four-port GbE uplinks)
Packet Switching Capacities56 Gbps
Layer 2 Throughput (Mpps)41.7 Mpps (wire speed)
Power Options
Power Supplies
  • 65 W AC Maximum System Power Consumption (Input Power without PoE)
  • 405 W Total PoE Power Budget
Environment
Operating Temperature32° to 113° F (0º to 45º C)
Storage Temperature-40º to 158º F (-40º to 70º C)
Relative Humidity (Operating)10% to 85% (noncondensing)
Relative Humidity (Non-Operating)0% to 95% (noncondensing)
Altitude (Operating)Up to 10,000 ft (3,048 m)
Altitude (Non-Operating)Up to 16,000 ft (4,877 m)
CoolingAirflow: 16.4 cfm
Noise Specifications
Noise SpecificationsNoise measurements based on operational tests taken from bystander position (front) and performed at 25° C in compliance with ISO 7779
Acoustic Noise in DBA37.2
Safety and Compliance
Safety Certifications
  • UL-UL60950-1 (First Edition)
  • C-UL to CAN/CSA 22.2 No.60950-1 (First Edition)
  • TUV/GS to EN 60950-1, Amendment A1-A4, A11
  • CB-IEC60950-1, all country deviations
Electromagnetic Compatibility Certifications
  • FCC 47CFR Part 15 Class A
  • EN 55022 Class A
  • ICES-003 Class A
  • VCCI Class A
  • AS/NZS CISPR 22 Class A
  • CISPR 22 Class A
  • EN 55024
  • EN 300386
  • CE
NEBS
  • GR-63-Core: NEBS, Physical Protection
  • GR-1089-Core: EMC and Electrical Safety for Network Telecommunications Equipment
  • All models except EX2200-24P-4G and EX2200-48P-4G
Telecom Quality Management TL9000
Environmental Reduction of Hazardous Substances (ROHS) 6
TelcoCLEI code
WarrantyLimited lifetime switch hardware warranty

Additional Feature Specifications:

Optics
  • 100 Mbps optic/connector type: LC SFP fiber supporting 100BASE- FX SFP (multimode) and BX (single strand)
  • 10/100/1000BASE-T connector type RJ-45
  • GbE SFP optic/connector type: RJ-45, or LC SFP fiber supporting 1000BASE-T SFP, SX (multimode), LX (single-mode), or LH/ZX (single-mode)

Physical Layer

  • Physical port redundancy: Redundant Trunk Group (RTG)
  • Time-domain reflectometry (TDR) for detecting cable breaks and shorts
  • Auto MDI/MDIX (medium-dependent interface/medium- dependent interface crossover) support
  • Port speed downshift/setting maximum advertised speed on 10/100/1000BASE-T ports
  • Digital optical monitoring for optical ports

Layer 2 Switching

  • Maximum MAC addresses in hardware: 16,000
  • Jumbo frames: 9216 bytes
  • Number of VLANs: 1,024 (VLAN IDs: 4,096)
  • Port-based VLAN
  • MAC-based VLAN
  • Voice VLAN
  • Private VLAN (PVLAN)
  • IEEE 802.1ak: Multiple VLAN Registration Protocol (MVRP)
  • Multicast VLAN Registration (MVR)
  • Compatible with Per-VLAN Spanning Tree Plus (PVST+)
  • RVI (Routed VLAN Interface)
  • IEEE 802.1AB: Link Layer Discovery Protocol (LLDP)
  • LLDP-MED with VoIP integration
  • IEEE 802.1D: Spanning Tree Protocol
  • IEEE 802.1p: CoS prioritization
  • IEEE 802.1Q: VLAN tagging
  • IEEE 802.1Q-in-Q: VLAN Stacking
  • IEEE 802.1s: Multiple Spanning Tree Protocol (MSTP)
  • Number of MST instances supported: 64
  • IEEE 802.1w: Rapid Spanning Tree Protocol (RSTP)
  • IEEE 802.1X: Port Access Control
  • IEEE 802.3: 10BASE-T
  • IEEE 802.3u: 100BASE-T
  • IEEE 802.3ab: 1000BASE-T
  • IEEE 802.3z: 1000BASE-X
  • IEEE 802.3af: PoE
  • IEEE 802.3at: PoE+
  • IEEE 802.3x: Pause Frames/Flow Control
  • IEEE 802.3ad: Link Aggregation Control Protocol (LACP)
  • IEEE 802.3ah: Ethernet in the First Mile
  • IEEE 802.1ag: Connectivity Fault Management (CFM)
  • G.8032 (Ethernet Ring Protection)

Layer 3 Features: IPv4

Juniper
  • Maximum number of Address Resolution Protocol (ARP) entries: 2,000
  • Maximum number of IPv4 unicast routes in hardware: 6500
  • Routing protocols:
  • RIP v1/v2
  • OSPF v1/v2 (with 4 active interfaces)
  • Static routing
  • Bidirectional Forwarding Detection (BFD)
  • IP directed broadcast
  • VRF-Lite

Layer 3 Features: IPv6 Management Functionality

  • Neighbor discovery, Syslog, Telnet, SSH, J-Web, SNMP, NTP, DNS
  • Static routing

Supported RFCs

  • RFC 3176 sFlow
  • RFC 2925 MIB for remote ping, trace
  • RFC 1122 Host requirements
  • RFC 768 UDP
  • RFC 791 IP
  • RFC 783 Trivial File Transfer Protocol (TFTP)
  • RFC 792 Internet Control Message Protocol (ICMP)
  • RFC 793 TCP
  • RFC 826 ARP
  • RFC 894 IP over Ethernet
  • RFC 903 Reverse ARP (RARP)
  • RFC 906 TFTP bootstrap
  • RFC 1027 Proxy ARP
  • RFC 2068 HTTP server
  • RFC 1812 Requirements for IP Version 4 routers
  • RFC 1519 Classless Interdomain Routing (CIDR)
  • RFC 1256 IPv4 ICMP Router Discovery (IRDP)
  • RFC 1058 RIP v1
  • RFC 2453 RIP v2
  • RFC 1492 TACACS+
  • RFC 2138 RADIUS authentication
  • RFC 2139 RADIUS accounting
  • RFC 3579 RADIUS Extensible Authentication Protocol (EAP) support for 802.1X
  • RFC 5176 Dynamic Authorization Extensions to RADIUS
  • RFC 2267 Network ingress filtering
  • RFC 2030 Simple Network Time Protocol (SNTP)
  • RFC 854 Telnet client and server
  • RFC 951, 1542 BootP
  • RFC 2131 BOOTP/DHCP relay agent and DHCP server
  • RFC 1591 Domain Name System (DNS)
  • RFC 2474 DiffServ Precedence, including 8 queues/port
  • RFC 2598 DiffServ Expedited Forwarding (EF)
  • RFC 2597 DiffServ Assured Forwarding (AF)
  • LLDP Media Endpoint Discovery (LLDP-MED), ANSI/TIA-1057, draft 08

Security

  • MAC limiting
  • Allowed MAC addresses—configurable per port
  • Sticky MAC (persistent MAC address learning)
  • Dynamic ARP inspection (DAI)
  • Proxy ARP
  • Static ARP support
  • DHCP snooping
  • IP source guard
  • 802.1X port-based
  • 802.1X multiple supplicants
  • 802.1X with VLAN assignment
  • 802.1X with authentication bypass access (based on host MAC address)
  • 802.1X with VoIP VLAN support
  • 802.1X dynamic ACL based on RADIUS attributes
  • 802.1X Supported EAP types: Message Digest 5 (MD5), Transport Layer Security (TLS), Tunneled Transport Layer Security (TTLS), Protected Extensible Authentication Protocol (PEAP)
  • Captive Portal
  • Trusted Network Connect (TNC) certified
  • Static MAC authentication
  • MAC-RADIUS
  • Control plane DoS protection
  • Fallback Authentication

Access control lists (ACLs) (Junos OS firewall filters)

  • Port-based ACL (PACL)—ingress
  • VLAN-based ACL (VACL)—ingress and egress
  • Router-based ACL (RACL)—ingress and egress
  • ACL entries (ACE) in hardware per system: 1,500
  • ACL counter for denied packets
  • ACL counter for permitted packets
  • Ability to add/remove/change ACL entries in middle of list (ACL editing)
  • L2-L4 ACL
High Availability
  • External redundant power system (RPS) option
  • Link Aggregation
  • 802.3ad (LACP) support:
    • Number of LAGs supported: 32
    • Maximum number of ports per LAG: 8
  • LAG load sharing algorithm—Bridged Unicast Traffic: IP: S/D MAC, S/D IP
    • TCP/UDP: S/D MAC, S/D IP, S/D Port Non-IP: S/D MAC
  • LAG sharing algorithm—Routed Unicast Traffic:
    • IP: S/D IP
    • TCP/UDP: S/D IP, S/D Port
  • LAG load sharing algorithm—Bridged Multicast Traffic:
    • IP: S/D MAC, S/D IP
    • TCP/UDP: S/D MAC, S/D IP, S/D Port Non-IP: S/D MAC
  • LAG sharing algorithm—Routed Multicast Traffic:
    • IP: S/D IP
    • TCP/UDP: S/D IP, S/D Port
  • Tagged ports support in LAG
  • Uplink Failure Detection (UFD)

Quality of Service (QoS)

  • Layer 2 QoS
  • Layer 3 QoS
  • Ingress policing: 1 rate 2 color
  • Hardware queues per port: 8
  • Scheduling methods (egress): Strict Priority (SP), shaped deficit weighted round-robin (SDWRR)
  • 802.1p, DSCP /IP precedence trust and marking
  • L2-L4 classification criteria: Interface, MAC address, Ethertype, 802.1p, VLAN, IP address, DSCP/IP precedence, TCP/UDP port numbers
  • Congestion avoidance capabilities: Tail drop

Juniper Ex2200 Software Upgrade Usb

Multicast

  • IGMP snooping entries: 1,000
  • IGMP: v1, v2, v3
  • IGMP snooping
  • PIM-SM, PIM-SSM, PIM-DM

Juniper Ex2200 Firmware Upgrade Usb

Services and Manageability

  • Junos OS CLI
  • Web interface (J-Web)
  • Out-of-band management: Serial, 10/100BASE-T Ethernet
  • ASCII configuration
  • Rescue configuration
  • Configuration rollback
  • Image rollback
  • Element management tools: Junos Space Network Management Platform
  • Real-time Performance Monitoring (RPM)
  • Simple Network Management Protocol (SNMP): v1, v2c, v3
  • Remote monitoring (RMON) (RFC 2819) Groups 1, 2, 3, 9
  • Network Time Protocol (NTP)
  • DHCP server
  • DHCP client and DHCP proxy
  • DHCP relay and helper
  • RADIUS authentication
  • TACACS+ authentication
  • SSHv2
  • Secure copy
  • HTTP/HTTPs
  • DNS resolver
  • Syslog logging
  • Temperature sensor
  • Configuration backup via FTP/secure copy
  • Interface range

Supported MIBs*

  • RFC 2464 Transmission of IPv6 Packets over Ethernet Networks
  • RFC 4862 IPv6 Stateless Address Autoconfiguration
  • RFC 4443 ICMPv6 for the IPv6 Specification
  • RFC 4213 Basic Transition Mechanisms for IPv6 Hosts and Routers
  • RFC 1155 Structure of Management Information (SMI)
  • RFC 1157 SNMPv1
  • RFC 1905 RFC 1907 SNMP v2c, SMIv2 and revised MIB-II
  • RFC 2570-2575 SNMPv3, user-based security, encryption, and authentication
  • RFC 2576 Coexistence between SNMP Version 1, Version 2 and Version 3
  • RFC 1212, RFC 1213, RFC 1215 MIB-II, Ethernet-like MIB, and TRAPs
  • RFC 2578 SNMP Structure of Management Information MIB
  • RFC 2579 SNMP Textual Conventions for SMIv2
  • RFC 2925 Ping/traceroute MIB
  • RFC 2665 Ethernet-like interface MIB
  • RFC 1643 Ethernet MIB
  • RFC 1493 Bridge MIB
  • RFC 2096 IPv4 Forwarding Table MIB
  • RFC 2011 SNMPv2 for IP using SMIv2
  • RFC 2012 SNMPv2 for transmission control protocol using SMIv2
  • RFC 2013 SNMPv2 for user datagram protocol using SMIv2
  • RFC 2863 Interface MIB
  • RFC 3413 SNMP Application MIB
  • RFC 3414 User-based security model for SNMPv3
  • RFC 3415 View-based Access Control Model for SNMP
  • RFC 3621 PoE-MIB (PoE switches only)
  • RFC 1724 RIPv2 MIB
  • RFC 2863 Interface Group MIB
  • RFC 2819 RMON MIB
  • RFC 2287 System Application Packages MIB
  • RFC 4188 STP and extensions MIB
  • RFC 4363 Definitions of managed objects for bridges with traffic classes, multicast filtering, and VLAN extensions
  • RFC 2922 LLDP MIB
  • RFC 1981 Path MTU discovery for IPv6
  • RFC 2460 IPv6 Specification
  • RFC 3484 Default address selection for IPv6
  • RFC 4291 IPv6 Addressing architecture
  • RFC 4861 Neighbor discovery for IPv6
  • Draft – blumenthal – aes – usm - 08
  • Draft – reeder - snmpv3 – usm - 3desede -00

Troubleshooting

  • Debugging: CLI via console, telnet, or SSH
  • Diagnostics: Show and debug command statistics
  • Traffic mirroring (port)
  • Traffic mirroring (VLAN)
  • ACL-based mirroring
  • Mirroring destination ports per system: 1
  • LAG port monitoring
  • Multiple destination ports monitored to 1 mirror (N:1)
  • Maximum number of mirroring sessions: 1
  • Mirroring to remote destination (over L2): 1 destination VLAN
  • IP tools: Extended ping and trace
  • Juniper Networks commit and rollback
*Each switch comes with RJ-45-to-DB-9 serial port adapter, 19' rack mount kit and connector retainer. Each system also ships with a power cord for the country for which it is shipped.

Views:



Front View

Right Angle View

Juniper Ex2200 Poe Firmware Upgrade


Documentation:

Download the Juniper Networks EX2200 Series Data Sheet (PDF).
